Poor mans impact analysis.

JM
Joe Metrisin
Thu, May 16, 2024 1:33 PM

I recall long ago, someone mentioned a way to do a simple, poor-mans impact
analysis instead of doing an explicit LS-Dyna solution.  It involved running
a static solution in ANSYS using a unit load force or pressure applied in
the manner you expect the impact to occur.  Then you scale the results by
ratioing the strain energy to the kinetic energy of the impacting object.
It's conservative because it assumes all the energy of the impact is
absorbed by the structure.

Sounds reasonable and conservative, but I'm struggling to find a way to
relate the strain energy of an arbitrary structure to the kinetic energy I
calculate.  Any ideas?
