APDL Command to Rename Directory

MR
Matthew Ridzon, PE
Wed, Jul 17, 2024 11:10 AM

Folks,

I'm writing an APDL script and would like to rename a file directory.  Is there a command for this?  To my knowledge, /RENAME is for files only, and not directories.

I considered /SYS, but I cannot use APDL character substitution inside of that command.

Matt Ridzon, PE, MSME
Sr. Engineering Analyst

Email    matt@prime-engineer.commailto:matt@prime-engineer.com
Mail      266 Main St, Burlington, VT 05401
Web      www.prime-engineer.comhttp://www.prime-engineer.com/
[A blue hexagon with white letters  Description automatically generated]
PRIME ENGINEERING LLC

This message (including any attachments) may contain confidential, proprietary, privileged and/or private information. The information is intended to be for the use of the individual or entity designated above. If you are not the intended recipient of this message, please notify the sender immediately, and delete the message and any attachments. Any disclosure, reproduction, distribution or other use of this message or any attachments by an individual or entity other than the intended recipient is prohibited.

Folks, I'm writing an APDL script and would like to rename a file directory. Is there a command for this? To my knowledge, /RENAME is for files only, and not directories. I considered /SYS, but I cannot use APDL character substitution inside of that command. Matt Ridzon, PE, MSME Sr. Engineering Analyst Email matt@prime-engineer.com<mailto:matt@prime-engineer.com> Mail 266 Main St, Burlington, VT 05401 Web www.prime-engineer.com<http://www.prime-engineer.com/> [A blue hexagon with white letters Description automatically generated] PRIME ENGINEERING LLC This message (including any attachments) may contain confidential, proprietary, privileged and/or private information. The information is intended to be for the use of the individual or entity designated above. If you are not the intended recipient of this message, please notify the sender immediately, and delete the message and any attachments. Any disclosure, reproduction, distribution or other use of this message or any attachments by an individual or entity other than the intended recipient is prohibited.
PJ
Patterson, James
Wed, Jul 17, 2024 11:16 AM

Matt,

I do this by writing a short macro on the fly in my main macro to execute the commands, then delete it right away.  Something like…

*cfopen,temp,mac
/sys,…
*cfclose

/inp,temp,mac
/sys,del temp.mac

Thanks,

Jim

[cid:image001.png@01DAD819.46B46360]
James J. Patterson, PhD.
Principal Vehicle Systems Engineer
Trailer Commercial Vehicle Systems
2070 Industrial Place S.E.  Canton, OH 44707
ph. 330 489 0095  |  fax 330 489 1961
jpatterson@hendrickson-intl.commailto:jpatterson@hendrickson-intl.com
www.hendrickson-intl.com
[cid:image002.gif@01DAD819.46B46360]

From: Matthew Ridzon, PE via Xansys xansys-temp@list.xansys.org
Sent: Wednesday, July 17, 2024 7:11 AM
To: xansys-temp@list.xansys.org
Cc: Matthew Ridzon, PE Matt@prime-engineer.com
Subject: [Xansys] APDL Command to Rename Directory

Folks, I'm writing an APDL script and would like to rename a file directory. Is there a command for this? To my knowledge, /RENAME is for files only, and not directories. I considered /SYS, but I cannot use APDL character substitution inside

Folks,

I'm writing an APDL script and would like to rename a file directory.  Is there a command for this?  To my knowledge, /RENAME is for files only, and not directories.

I considered /SYS, but I cannot use APDL character substitution inside of that command.

Matt Ridzon, PE, MSME

Sr. Engineering Analyst

Email    matt@prime-engineer.com<mailto:matt@prime-engineer.commailto:matt@prime-engineer.com%3cmailto:matt@prime-engineer.com>

Mail      266 Main St, Burlington, VT 05401

Web      https://urldefense.com/v3/http://www.prime-engineer.com;!!HXcklc0VomgEZw!5P6gqv6Kn4t2xaD1yBdkxi_HoYX-f-1FRgcq-eUdOJUnhkjJg5M0f4Ck0mG8BT-Z-BF_36MizTzvZPZkLCzFbW07tXIgoJTeqkU$https://urldefense.com/v3/__http:/www.prime-engineer.com__;!!HXcklc0VomgEZw!5P6gqv6Kn4t2xaD1yBdkxi_HoYX-f-1FRgcq-eUdOJUnhkjJg5M0f4Ck0mG8BT-Z-BF_36MizTzvZPZkLCzFbW07tXIgoJTeqkU$<https://urldefense.com/v3/http://www.prime-engineer.com/;!!HXcklc0VomgEZw!5P6gqv6Kn4t2xaD1yBdkxi_HoYX-f-1FRgcq-eUdOJUnhkjJg5M0f4Ck0mG8BT-Z-BF_36MizTzvZPZkLCzFbW07tXIgZyA822w$https://urldefense.com/v3/__http:/www.prime-engineer.com/__;!!HXcklc0VomgEZw!5P6gqv6Kn4t2xaD1yBdkxi_HoYX-f-1FRgcq-eUdOJUnhkjJg5M0f4Ck0mG8BT-Z-BF_36MizTzvZPZkLCzFbW07tXIgZyA822w$>

[A blue hexagon with white letters  Description automatically generated]

PRIME ENGINEERING LLC

This message (including any attachments) may contain confidential, proprietary, privileged and/or private information. The information is intended to be for the use of the individual or entity designated above. If you are not the intended recipient of this message, please notify the sender immediately, and delete the message and any attachments. Any disclosure, reproduction, distribution or other use of this message or any attachments by an individual or entity other than the intended recipient is prohibited.

The contents of this message may be privileged and confidential. Therefore, if this message has been received in error, please delete it without reading it. Your receipt of this message is not intended to waive any applicable privilege. Please do not disseminate this message without the permission of the author.

Matt, I do this by writing a short macro on the fly in my main macro to execute the commands, then delete it right away. Something like… *cfopen,temp,mac /sys,… *cfclose /inp,temp,mac /sys,del temp.mac Thanks, Jim [cid:image001.png@01DAD819.46B46360] James J. Patterson, PhD. Principal Vehicle Systems Engineer Trailer Commercial Vehicle Systems 2070 Industrial Place S.E. Canton, OH 44707 ph. 330 489 0095 | fax 330 489 1961 jpatterson@hendrickson-intl.com<mailto:jpatterson@hendrickson-intl.com> www.hendrickson-intl.com [cid:image002.gif@01DAD819.46B46360] From: Matthew Ridzon, PE via Xansys <xansys-temp@list.xansys.org> Sent: Wednesday, July 17, 2024 7:11 AM To: xansys-temp@list.xansys.org Cc: Matthew Ridzon, PE <Matt@prime-engineer.com> Subject: [Xansys] APDL Command to Rename Directory Folks, I'm writing an APDL script and would like to rename a file directory. Is there a command for this? To my knowledge, /RENAME is for files only, and not directories. I considered /SYS, but I cannot use APDL character substitution inside Folks, I'm writing an APDL script and would like to rename a file directory. Is there a command for this? To my knowledge, /RENAME is for files only, and not directories. I considered /SYS, but I cannot use APDL character substitution inside of that command. Matt Ridzon, PE, MSME Sr. Engineering Analyst Email matt@prime-engineer.com<mailto:matt@prime-engineer.com<mailto:matt@prime-engineer.com%3cmailto:matt@prime-engineer.com>> Mail 266 Main St, Burlington, VT 05401 Web https://urldefense.com/v3/__http://www.prime-engineer.com__;!!HXcklc0VomgEZw!5P6gqv6Kn4t2xaD1yBdkxi_HoYX-f-1FRgcq-eUdOJUnhkjJg5M0f4Ck0mG8BT-Z-BF_36MizTzvZPZkLCzFbW07tXIgoJTeqkU$<https://urldefense.com/v3/__http:/www.prime-engineer.com__;!!HXcklc0VomgEZw!5P6gqv6Kn4t2xaD1yBdkxi_HoYX-f-1FRgcq-eUdOJUnhkjJg5M0f4Ck0mG8BT-Z-BF_36MizTzvZPZkLCzFbW07tXIgoJTeqkU$><https://urldefense.com/v3/__http://www.prime-engineer.com/__;!!HXcklc0VomgEZw!5P6gqv6Kn4t2xaD1yBdkxi_HoYX-f-1FRgcq-eUdOJUnhkjJg5M0f4Ck0mG8BT-Z-BF_36MizTzvZPZkLCzFbW07tXIgZyA822w$<https://urldefense.com/v3/__http:/www.prime-engineer.com/__;!!HXcklc0VomgEZw!5P6gqv6Kn4t2xaD1yBdkxi_HoYX-f-1FRgcq-eUdOJUnhkjJg5M0f4Ck0mG8BT-Z-BF_36MizTzvZPZkLCzFbW07tXIgZyA822w$>> [A blue hexagon with white letters Description automatically generated] PRIME ENGINEERING LLC This message (including any attachments) may contain confidential, proprietary, privileged and/or private information. The information is intended to be for the use of the individual or entity designated above. If you are not the intended recipient of this message, please notify the sender immediately, and delete the message and any attachments. Any disclosure, reproduction, distribution or other use of this message or any attachments by an individual or entity other than the intended recipient is prohibited. The contents of this message may be privileged and confidential. Therefore, if this message has been received in error, please delete it without reading it. Your receipt of this message is not intended to waive any applicable privilege. Please do not disseminate this message without the permission of the author.
UD
Uffe Dal Eriksen
Wed, Jul 17, 2024 12:17 PM

Matt,

Regarding character substitution inside /SYS command (or similar), the old trick is to write the desired command line(s) to a separate file and then execute the file using /INPUT.

Like:

*CFOPEN,file,inp
*VWRITE, oldfolder,newfolder
/SYS, ren %C %C
*CFCLOSE
/INPUT,file,inp

Not checked... at least it is a start.

Uffe Dal Eriksen
Ramboll
Energy Transition, Marine Structures
Denmark

Classification: Confidential
-----Original Message-----
From: Matthew Ridzon, PE via Xansys xansys-temp@list.xansys.org
Sent: 17. juli 2024 13:11
To: xansys-temp@list.xansys.org
Cc: Matthew Ridzon, PE Matt@prime-engineer.com
Subject: [Xansys] APDL Command to Rename Directory

Folks,

I'm writing an APDL script and would like to rename a file directory.  Is there a command for this?  To my knowledge, /RENAME is for files only, and not directories.

I considered /SYS, but I cannot use APDL character substitution inside of that command.

Matt Ridzon, PE, MSME
Sr. Engineering Analyst

Email    matt@prime-engineer.commailto:matt@prime-engineer.com
Mail      266 Main St, Burlington, VT 05401
Web      http://www.prime-engineer.com/http://www.prime-engineer.com/
[A blue hexagon with white letters  Description automatically generated] PRIME ENGINEERING LLC

This message (including any attachments) may contain confidential, proprietary, privileged and/or private information. The information is intended to be for the use of the individual or entity designated above. If you are not the intended recipient of this message, please notify the sender immediately, and delete the message and any attachments. Any disclosure, reproduction, distribution or other use of this message or any attachments by an individual or entity other than the intended recipient is prohibited.

Matt, Regarding character substitution inside /SYS command (or similar), the old trick is to write the desired command line(s) to a separate file and then execute the file using /INPUT. Like: *CFOPEN,file,inp *VWRITE, oldfolder,newfolder /SYS, ren %C %C *CFCLOSE /INPUT,file,inp Not checked... at least it is a start. Uffe Dal Eriksen Ramboll Energy Transition, Marine Structures Denmark Classification: Confidential -----Original Message----- From: Matthew Ridzon, PE via Xansys <xansys-temp@list.xansys.org> Sent: 17. juli 2024 13:11 To: xansys-temp@list.xansys.org Cc: Matthew Ridzon, PE <Matt@prime-engineer.com> Subject: [Xansys] APDL Command to Rename Directory Folks, I'm writing an APDL script and would like to rename a file directory. Is there a command for this? To my knowledge, /RENAME is for files only, and not directories. I considered /SYS, but I cannot use APDL character substitution inside of that command. Matt Ridzon, PE, MSME Sr. Engineering Analyst Email matt@prime-engineer.com<mailto:matt@prime-engineer.com> Mail 266 Main St, Burlington, VT 05401 Web http://www.prime-engineer.com/<http://www.prime-engineer.com/> [A blue hexagon with white letters Description automatically generated] PRIME ENGINEERING LLC This message (including any attachments) may contain confidential, proprietary, privileged and/or private information. The information is intended to be for the use of the individual or entity designated above. If you are not the intended recipient of this message, please notify the sender immediately, and delete the message and any attachments. Any disclosure, reproduction, distribution or other use of this message or any attachments by an individual or entity other than the intended recipient is prohibited.
JM
Joe Metrisin
Wed, Jul 17, 2024 12:30 PM

Hey Matt,

Have a look at the /SYP command.  It's similar to /SYS but allows arguments
to be passed.  Never tried it with character arguments though.

Joseph T Metrisin
Structures Lead

Florida Turbine Technologies, Inc
1701 Military Tr. Suite 110 | Jupiter, FL 33458 USA
+1 (561) 427-6346 Office | +1 (772) 834-4156 Mobile
Joe.Metrisin@kratosdefense.com

Visit our website: https://kratosdefense.com

Confidentiality Note:
The information contained in this transmission and any attachments are
proprietary and may be privileged, intended only for the use of the
individual or entity named above. If the reader of this message is not the
intended recipient, you are hereby notified that any dissemination,
distribution, or copying of this communication is strictly prohibited.  If
you received this communication in error, please delete the message and
immediately notify the sender via the contact information listed above.

-----Original Message-----
From: Matthew Ridzon, PE via Xansys xansys-temp@list.xansys.org
Sent: Wednesday, July 17, 2024 7:11 AM
To: xansys-temp@list.xansys.org
Cc: Matthew Ridzon, PE Matt@prime-engineer.com
Subject: [External] - [Xansys] APDL Command to Rename Directory

CAUTION: This email originated from outside of the organization. Do not
click links or open attachments unless you recognize the sender and know the
content is safe.

Folks,

I'm writing an APDL script and would like to rename a file directory.  Is
there a command for this?  To my knowledge, /RENAME is for files only, and
not directories.

I considered /SYS, but I cannot use APDL character substitution inside of
that command.

Matt Ridzon, PE, MSME
Sr. Engineering Analyst

Email    matt@prime-engineer.commailto:matt@prime-engineer.com
Mail      266 Main St, Burlington, VT 05401
Web
https://urldefense.com/v3/http://www.prime-engineer.com;!!KM6X6ZXWXVtZMQ
!cYVVW-0jiTbilQjuF7RAPMQb9LIlOI6AOHFP3Q1ol-L87BlBdPybYnAIOvjwC0wRxTSMBh725z_
q1BqJQXQg2Mp6Zh4nPf521g$
<https://urldefense.com/v3/http://www.prime-engineer.com/;!!KM6X6ZXWXVtZ
MQ!cYVVW-0jiTbilQjuF7RAPMQb9LIlOI6AOHFP3Q1ol-L87BlBdPybYnAIOvjwC0wRxTSMBh725
z_q1BqJQXQg2Mp6Zh4SJrj7sg$ >
[A blue hexagon with white letters  Description automatically generated]
PRIME ENGINEERING LLC

This message (including any attachments) may contain confidential,
proprietary, privileged and/or private information. The information is
intended to be for the use of the individual or entity designated above. If
you are not the intended recipient of this message, please notify the sender
immediately, and delete the message and any attachments. Any disclosure,
reproduction, distribution or other use of this message or any attachments
by an individual or entity other than the intended recipient is prohibited.

Hey Matt, Have a look at the /SYP command. It's similar to /SYS but allows arguments to be passed. Never tried it with character arguments though. Joseph T Metrisin Structures Lead Florida Turbine Technologies, Inc 1701 Military Tr. Suite 110 | Jupiter, FL 33458 USA +1 (561) 427-6346 Office | +1 (772) 834-4156 Mobile Joe.Metrisin@kratosdefense.com Visit our website: https://kratosdefense.com Confidentiality Note: The information contained in this transmission and any attachments are proprietary and may be privileged, intended only for the use of the individual or entity named above. If the reader of this message is not the intended recipient, you are hereby notified that any dissemination, distribution, or copying of this communication is strictly prohibited.  If you received this communication in error, please delete the message and immediately notify the sender via the contact information listed above. -----Original Message----- From: Matthew Ridzon, PE via Xansys <xansys-temp@list.xansys.org> Sent: Wednesday, July 17, 2024 7:11 AM To: xansys-temp@list.xansys.org Cc: Matthew Ridzon, PE <Matt@prime-engineer.com> Subject: [External] - [Xansys] APDL Command to Rename Directory CAUTION: This email originated from outside of the organization. Do not click links or open attachments unless you recognize the sender and know the content is safe. Folks, I'm writing an APDL script and would like to rename a file directory. Is there a command for this? To my knowledge, /RENAME is for files only, and not directories. I considered /SYS, but I cannot use APDL character substitution inside of that command. Matt Ridzon, PE, MSME Sr. Engineering Analyst Email matt@prime-engineer.com<mailto:matt@prime-engineer.com> Mail 266 Main St, Burlington, VT 05401 Web https://urldefense.com/v3/__http://www.prime-engineer.com__;!!KM6X6ZXWXVtZMQ !cYVVW-0jiTbilQjuF7RAPMQb9LIlOI6AOHFP3Q1ol-L87BlBdPybYnAIOvjwC0wRxTSMBh725z_ q1BqJQXQg2Mp6Zh4nPf521g$ <https://urldefense.com/v3/__http://www.prime-engineer.com/__;!!KM6X6ZXWXVtZ MQ!cYVVW-0jiTbilQjuF7RAPMQb9LIlOI6AOHFP3Q1ol-L87BlBdPybYnAIOvjwC0wRxTSMBh725 z_q1BqJQXQg2Mp6Zh4SJrj7sg$ > [A blue hexagon with white letters Description automatically generated] PRIME ENGINEERING LLC This message (including any attachments) may contain confidential, proprietary, privileged and/or private information. The information is intended to be for the use of the individual or entity designated above. If you are not the intended recipient of this message, please notify the sender immediately, and delete the message and any attachments. Any disclosure, reproduction, distribution or other use of this message or any attachments by an individual or entity other than the intended recipient is prohibited.
IG
Iker Gomez
Wed, Jul 17, 2024 4:48 PM

Look at /syp command instead

El mié, 17 de jul de 2024, 05:14, Matthew Ridzon, PE via Xansys <
xansys-temp@list.xansys.org> escribió:

Folks,

I'm writing an APDL script and would like to rename a file directory.  Is
there a command for this?  To my knowledge, /RENAME is for files only, and
not directories.

I considered /SYS, but I cannot use APDL character substitution inside of
that command.

Matt Ridzon, PE, MSME
Sr. Engineering Analyst

Email    matt@prime-engineer.commailto:matt@prime-engineer.com
Mail      266 Main St, Burlington, VT 05401
Web      www.prime-engineer.comhttp://www.prime-engineer.com/
[A blue hexagon with white letters  Description automatically generated]
PRIME ENGINEERING LLC

This message (including any attachments) may contain confidential,
proprietary, privileged and/or private information. The information is
intended to be for the use of the individual or entity designated above. If
you are not the intended recipient of this message, please notify the
sender immediately, and delete the message and any attachments. Any
disclosure, reproduction, distribution or other use of this message or any
attachments by an individual or entity other than the intended recipient is
prohibited.


Xansys mailing list -- xansys-temp@list.xansys.org
To unsubscribe send an email to xansys-temp-leave@list.xansys.org
If you are receiving too many emails from XANSYS please consider changing
account settings to Digest mode which will send a single email per day.

Please send administrative requests such as deletion from XANSYS to
xansys-mod@tynecomp.co.uk and not to the list

Look at /syp command instead El mié, 17 de jul de 2024, 05:14, Matthew Ridzon, PE via Xansys < xansys-temp@list.xansys.org> escribió: > Folks, > > I'm writing an APDL script and would like to rename a file directory. Is > there a command for this? To my knowledge, /RENAME is for files only, and > not directories. > > I considered /SYS, but I cannot use APDL character substitution inside of > that command. > > Matt Ridzon, PE, MSME > Sr. Engineering Analyst > > Email matt@prime-engineer.com<mailto:matt@prime-engineer.com> > Mail 266 Main St, Burlington, VT 05401 > Web www.prime-engineer.com<http://www.prime-engineer.com/> > [A blue hexagon with white letters Description automatically generated] > PRIME ENGINEERING LLC > > > This message (including any attachments) may contain confidential, > proprietary, privileged and/or private information. The information is > intended to be for the use of the individual or entity designated above. If > you are not the intended recipient of this message, please notify the > sender immediately, and delete the message and any attachments. Any > disclosure, reproduction, distribution or other use of this message or any > attachments by an individual or entity other than the intended recipient is > prohibited. > > > _______________________________________________ > Xansys mailing list -- xansys-temp@list.xansys.org > To unsubscribe send an email to xansys-temp-leave@list.xansys.org > If you are receiving too many emails from XANSYS please consider changing > account settings to Digest mode which will send a single email per day. > > Please send administrative requests such as deletion from XANSYS to > xansys-mod@tynecomp.co.uk and not to the list
MR
Matthew Ridzon, PE
Wed, Jul 17, 2024 5:21 PM

Can anyone show me an example of /SYP?  It's unclear to me how to write the syntax with a system command, but also feed arguments.  The documentation for /SYP is not very helpful.

—Matt

-----Original Message-----
From: Iker Gomez via Xansys xansys-temp@list.xansys.org
Sent: Wednesday, July 17, 2024 12:48 PM
To: XANSYS Mailing List Home xansys-temp@list.xansys.org
Cc: Iker Gomez iker.gomez.vazquez@gmail.com
Subject: [Xansys] Re: APDL Command to Rename Directory

Look at /syp command instead

El mié, 17 de jul de 2024, 05:14, Matthew Ridzon, PE via Xansys < xansys-temp@list.xansys.org> escribió:

Folks,

I'm writing an APDL script and would like to rename a file directory.
Is there a command for this?  To my knowledge, /RENAME is for files
only, and not directories.

I considered /SYS, but I cannot use APDL character substitution inside
of that command.

Matt Ridzon, PE, MSME
Sr. Engineering Analyst

Email    matt@prime-engineer.commailto:matt@prime-engineer.com
Mail      266 Main St, Burlington, VT 05401
Web      www.prime-engineer.comhttp://www.prime-engineer.com/
[A blue hexagon with white letters  Description automatically
generated] PRIME ENGINEERING LLC

This message (including any attachments) may contain confidential,
proprietary, privileged and/or private information. The information is
intended to be for the use of the individual or entity designated
above. If you are not the intended recipient of this message, please
notify the sender immediately, and delete the message and any
attachments. Any disclosure, reproduction, distribution or other use
of this message or any attachments by an individual or entity other
than the intended recipient is prohibited.


Xansys mailing list -- xansys-temp@list.xansys.org To unsubscribe send
an email to xansys-temp-leave@list.xansys.org If you are receiving too
many emails from XANSYS please consider changing account settings to
Digest mode which will send a single email per day.

Please send administrative requests such as deletion from XANSYS to
xansys-mod@tynecomp.co.uk and not to the list


Xansys mailing list -- xansys-temp@list.xansys.org To unsubscribe send an email to xansys-temp-leave@list.xansys.org If you are receiving too many emails from XANSYS please consider changing account settings to Digest mode which will send a single email per day.

Please send administrative requests such as deletion from XANSYS to xansys-mod@tynecomp.co.uk and not to the list

Can anyone show me an example of /SYP? It's unclear to me how to write the syntax with a system command, but also feed arguments. The documentation for /SYP is not very helpful. —Matt -----Original Message----- From: Iker Gomez via Xansys <xansys-temp@list.xansys.org> Sent: Wednesday, July 17, 2024 12:48 PM To: XANSYS Mailing List Home <xansys-temp@list.xansys.org> Cc: Iker Gomez <iker.gomez.vazquez@gmail.com> Subject: [Xansys] Re: APDL Command to Rename Directory Look at /syp command instead El mié, 17 de jul de 2024, 05:14, Matthew Ridzon, PE via Xansys < xansys-temp@list.xansys.org> escribió: > Folks, > > I'm writing an APDL script and would like to rename a file directory. > Is there a command for this? To my knowledge, /RENAME is for files > only, and not directories. > > I considered /SYS, but I cannot use APDL character substitution inside > of that command. > > Matt Ridzon, PE, MSME > Sr. Engineering Analyst > > Email matt@prime-engineer.com<mailto:matt@prime-engineer.com> > Mail 266 Main St, Burlington, VT 05401 > Web www.prime-engineer.com<http://www.prime-engineer.com/> > [A blue hexagon with white letters Description automatically > generated] PRIME ENGINEERING LLC > > > This message (including any attachments) may contain confidential, > proprietary, privileged and/or private information. The information is > intended to be for the use of the individual or entity designated > above. If you are not the intended recipient of this message, please > notify the sender immediately, and delete the message and any > attachments. Any disclosure, reproduction, distribution or other use > of this message or any attachments by an individual or entity other > than the intended recipient is prohibited. > > > _______________________________________________ > Xansys mailing list -- xansys-temp@list.xansys.org To unsubscribe send > an email to xansys-temp-leave@list.xansys.org If you are receiving too > many emails from XANSYS please consider changing account settings to > Digest mode which will send a single email per day. > > Please send administrative requests such as deletion from XANSYS to > xansys-mod@tynecomp.co.uk and not to the list _______________________________________________ Xansys mailing list -- xansys-temp@list.xansys.org To unsubscribe send an email to xansys-temp-leave@list.xansys.org If you are receiving too many emails from XANSYS please consider changing account settings to Digest mode which will send a single email per day. Please send administrative requests such as deletion from XANSYS to xansys-mod@tynecomp.co.uk and not to the list
MG
Mohammad Gharaibeh
Wed, Jul 17, 2024 5:42 PM

Here is something:

SYP,mkdir ,'mytest'  ! Create new working directory in the current WD
/CWD,'C:\default_workdir\mytest'  ! Change WD to the new one
save  ! save .db

I hope this helps.

Best,
Mohammad

---====
Mohammad A Gharaibeh, Ph.D.
Associate Professor
Department of Mechanical Engineering
The Hashemite University
P.O. Box 330127
Zarqa, 13133, Jordan
Tel: +962 - 5 - 390 3333 Ext. 4771
Fax: +962 - 5 - 382 6348

---====

On Wed, 17 Jul 2024 at 8:22 PM Matthew Ridzon, PE via Xansys <
xansys-temp@list.xansys.org> wrote:

Can anyone show me an example of /SYP?  It's unclear to me how to write
the syntax with a system command, but also feed arguments.  The
documentation for /SYP is not very helpful.

—Matt

-----Original Message-----
From: Iker Gomez via Xansys xansys-temp@list.xansys.org
Sent: Wednesday, July 17, 2024 12:48 PM
To: XANSYS Mailing List Home xansys-temp@list.xansys.org
Cc: Iker Gomez iker.gomez.vazquez@gmail.com
Subject: [Xansys] Re: APDL Command to Rename Directory

Look at /syp command instead

El mié, 17 de jul de 2024, 05:14, Matthew Ridzon, PE via Xansys <
xansys-temp@list.xansys.org> escribió:

Folks,

I'm writing an APDL script and would like to rename a file directory.
Is there a command for this?  To my knowledge, /RENAME is for files
only, and not directories.

I considered /SYS, but I cannot use APDL character substitution inside
of that command.

Matt Ridzon, PE, MSME
Sr. Engineering Analyst

Email    matt@prime-engineer.commailto:matt@prime-engineer.com
Mail      266 Main St, Burlington, VT 05401
Web      www.prime-engineer.comhttp://www.prime-engineer.com/
[A blue hexagon with white letters  Description automatically
generated] PRIME ENGINEERING LLC

This message (including any attachments) may contain confidential,
proprietary, privileged and/or private information. The information is
intended to be for the use of the individual or entity designated
above. If you are not the intended recipient of this message, please
notify the sender immediately, and delete the message and any
attachments. Any disclosure, reproduction, distribution or other use
of this message or any attachments by an individual or entity other
than the intended recipient is prohibited.


Xansys mailing list -- xansys-temp@list.xansys.org To unsubscribe send
an email to xansys-temp-leave@list.xansys.org If you are receiving too
many emails from XANSYS please consider changing account settings to
Digest mode which will send a single email per day.

Please send administrative requests such as deletion from XANSYS to
xansys-mod@tynecomp.co.uk and not to the list


Xansys mailing list -- xansys-temp@list.xansys.org To unsubscribe send an
email to xansys-temp-leave@list.xansys.org If you are receiving too many
emails from XANSYS please consider changing account settings to Digest mode
which will send a single email per day.

Please send administrative requests such as deletion from XANSYS to
xansys-mod@tynecomp.co.uk and not to the list


Xansys mailing list -- xansys-temp@list.xansys.org
To unsubscribe send an email to xansys-temp-leave@list.xansys.org
If you are receiving too many emails from XANSYS please consider changing
account settings to Digest mode which will send a single email per day.

Please send administrative requests such as deletion from XANSYS to
xansys-mod@tynecomp.co.uk and not to the list

Here is something: SYP,mkdir ,'mytest' ! Create new working directory in the current WD /CWD,'C:\default_workdir\mytest' ! Change WD to the new one save ! save .db I hope this helps. Best, Mohammad ===================================== Mohammad A Gharaibeh, Ph.D. Associate Professor Department of Mechanical Engineering The Hashemite University P.O. Box 330127 Zarqa, 13133, Jordan Tel: +962 - 5 - 390 3333 Ext. 4771 Fax: +962 - 5 - 382 6348 ===================================== On Wed, 17 Jul 2024 at 8:22 PM Matthew Ridzon, PE via Xansys < xansys-temp@list.xansys.org> wrote: > Can anyone show me an example of /SYP? It's unclear to me how to write > the syntax with a system command, but also feed arguments. The > documentation for /SYP is not very helpful. > > —Matt > > -----Original Message----- > From: Iker Gomez via Xansys <xansys-temp@list.xansys.org> > Sent: Wednesday, July 17, 2024 12:48 PM > To: XANSYS Mailing List Home <xansys-temp@list.xansys.org> > Cc: Iker Gomez <iker.gomez.vazquez@gmail.com> > Subject: [Xansys] Re: APDL Command to Rename Directory > > Look at /syp command instead > > El mié, 17 de jul de 2024, 05:14, Matthew Ridzon, PE via Xansys < > xansys-temp@list.xansys.org> escribió: > > > Folks, > > > > I'm writing an APDL script and would like to rename a file directory. > > Is there a command for this? To my knowledge, /RENAME is for files > > only, and not directories. > > > > I considered /SYS, but I cannot use APDL character substitution inside > > of that command. > > > > Matt Ridzon, PE, MSME > > Sr. Engineering Analyst > > > > Email matt@prime-engineer.com<mailto:matt@prime-engineer.com> > > Mail 266 Main St, Burlington, VT 05401 > > Web www.prime-engineer.com<http://www.prime-engineer.com/> > > [A blue hexagon with white letters Description automatically > > generated] PRIME ENGINEERING LLC > > > > > > This message (including any attachments) may contain confidential, > > proprietary, privileged and/or private information. The information is > > intended to be for the use of the individual or entity designated > > above. If you are not the intended recipient of this message, please > > notify the sender immediately, and delete the message and any > > attachments. Any disclosure, reproduction, distribution or other use > > of this message or any attachments by an individual or entity other > > than the intended recipient is prohibited. > > > > > > _______________________________________________ > > Xansys mailing list -- xansys-temp@list.xansys.org To unsubscribe send > > an email to xansys-temp-leave@list.xansys.org If you are receiving too > > many emails from XANSYS please consider changing account settings to > > Digest mode which will send a single email per day. > > > > Please send administrative requests such as deletion from XANSYS to > > xansys-mod@tynecomp.co.uk and not to the list > _______________________________________________ > Xansys mailing list -- xansys-temp@list.xansys.org To unsubscribe send an > email to xansys-temp-leave@list.xansys.org If you are receiving too many > emails from XANSYS please consider changing account settings to Digest mode > which will send a single email per day. > > Please send administrative requests such as deletion from XANSYS to > xansys-mod@tynecomp.co.uk and not to the list > _______________________________________________ > Xansys mailing list -- xansys-temp@list.xansys.org > To unsubscribe send an email to xansys-temp-leave@list.xansys.org > If you are receiving too many emails from XANSYS please consider changing > account settings to Digest mode which will send a single email per day. > > Please send administrative requests such as deletion from XANSYS to > xansys-mod@tynecomp.co.uk and not to the list
MG
Mohammad Gharaibeh
Wed, Jul 17, 2024 5:44 PM

Oops!

Please correct to:

/SYP,mkdir ,'mytest'  ! Create new working directory in the current WD
/CWD,'C:\default_workdir\mytest'  ! Change WD to the new one
save  ! save .db

I skipped the “/“ in SYP in the previous email.

Good luck!

---====
Mohammad A Gharaibeh, Ph.D.
Associate Professor
Department of Mechanical Engineering
The Hashemite University
P.O. Box 330127
Zarqa, 13133, Jordan
Tel: +962 - 5 - 390 3333 Ext. 4771
Fax: +962 - 5 - 382 6348

---====

On Wed, 17 Jul 2024 at 8:42 PM Mohammad Gharaibeh mgharai1@binghamton.edu
wrote:

Here is something:

SYP,mkdir ,'mytest'  ! Create new working directory in the current WD
/CWD,'C:\default_workdir\mytest'  ! Change WD to the new one
save  ! save .db

I hope this helps.

Best,
Mohammad

---====
Mohammad A Gharaibeh, Ph.D.
Associate Professor
Department of Mechanical Engineering
The Hashemite University
P.O. Box 330127
Zarqa, 13133, Jordan
Tel: +962 - 5 - 390 3333 Ext. 4771
Fax: +962 - 5 - 382 6348

---====

On Wed, 17 Jul 2024 at 8:22 PM Matthew Ridzon, PE via Xansys <
xansys-temp@list.xansys.org> wrote:

Can anyone show me an example of /SYP?  It's unclear to me how to write
the syntax with a system command, but also feed arguments.  The
documentation for /SYP is not very helpful.

—Matt

-----Original Message-----
From: Iker Gomez via Xansys xansys-temp@list.xansys.org
Sent: Wednesday, July 17, 2024 12:48 PM
To: XANSYS Mailing List Home xansys-temp@list.xansys.org
Cc: Iker Gomez iker.gomez.vazquez@gmail.com
Subject: [Xansys] Re: APDL Command to Rename Directory

Look at /syp command instead

El mié, 17 de jul de 2024, 05:14, Matthew Ridzon, PE via Xansys <
xansys-temp@list.xansys.org> escribió:

Folks,

I'm writing an APDL script and would like to rename a file directory.
Is there a command for this?  To my knowledge, /RENAME is for files
only, and not directories.

I considered /SYS, but I cannot use APDL character substitution inside
of that command.

Matt Ridzon, PE, MSME
Sr. Engineering Analyst

Email    matt@prime-engineer.commailto:matt@prime-engineer.com
Mail      266 Main St, Burlington, VT 05401
Web      www.prime-engineer.comhttp://www.prime-engineer.com/
[A blue hexagon with white letters  Description automatically
generated] PRIME ENGINEERING LLC

This message (including any attachments) may contain confidential,
proprietary, privileged and/or private information. The information is
intended to be for the use of the individual or entity designated
above. If you are not the intended recipient of this message, please
notify the sender immediately, and delete the message and any
attachments. Any disclosure, reproduction, distribution or other use
of this message or any attachments by an individual or entity other
than the intended recipient is prohibited.


Xansys mailing list -- xansys-temp@list.xansys.org To unsubscribe send
an email to xansys-temp-leave@list.xansys.org If you are receiving too
many emails from XANSYS please consider changing account settings to
Digest mode which will send a single email per day.

Please send administrative requests such as deletion from XANSYS to
xansys-mod@tynecomp.co.uk and not to the list


Xansys mailing list -- xansys-temp@list.xansys.org To unsubscribe send
an email to xansys-temp-leave@list.xansys.org If you are receiving too
many emails from XANSYS please consider changing account settings to Digest
mode which will send a single email per day.

Please send administrative requests such as deletion from XANSYS to
xansys-mod@tynecomp.co.uk and not to the list


Xansys mailing list -- xansys-temp@list.xansys.org
To unsubscribe send an email to xansys-temp-leave@list.xansys.org
If you are receiving too many emails from XANSYS please consider changing
account settings to Digest mode which will send a single email per day.

Please send administrative requests such as deletion from XANSYS to
xansys-mod@tynecomp.co.uk and not to the list

Oops! Please correct to: /SYP,mkdir ,'mytest' ! Create new working directory in the current WD /CWD,'C:\default_workdir\mytest' ! Change WD to the new one save ! save .db I skipped the “/“ in SYP in the previous email. Good luck! ===================================== Mohammad A Gharaibeh, Ph.D. Associate Professor Department of Mechanical Engineering The Hashemite University P.O. Box 330127 Zarqa, 13133, Jordan Tel: +962 - 5 - 390 3333 Ext. 4771 Fax: +962 - 5 - 382 6348 ===================================== On Wed, 17 Jul 2024 at 8:42 PM Mohammad Gharaibeh <mgharai1@binghamton.edu> wrote: > Here is something: > > > SYP,mkdir ,'mytest' ! Create new working directory in the current WD > /CWD,'C:\default_workdir\mytest' ! Change WD to the new one > save ! save .db > > > I hope this helps. > > Best, > Mohammad > ===================================== > Mohammad A Gharaibeh, Ph.D. > Associate Professor > Department of Mechanical Engineering > The Hashemite University > P.O. Box 330127 > Zarqa, 13133, Jordan > Tel: +962 - 5 - 390 3333 Ext. 4771 > Fax: +962 - 5 - 382 6348 > ===================================== > > > > > On Wed, 17 Jul 2024 at 8:22 PM Matthew Ridzon, PE via Xansys < > xansys-temp@list.xansys.org> wrote: > >> Can anyone show me an example of /SYP? It's unclear to me how to write >> the syntax with a system command, but also feed arguments. The >> documentation for /SYP is not very helpful. >> >> —Matt >> >> -----Original Message----- >> From: Iker Gomez via Xansys <xansys-temp@list.xansys.org> >> Sent: Wednesday, July 17, 2024 12:48 PM >> To: XANSYS Mailing List Home <xansys-temp@list.xansys.org> >> Cc: Iker Gomez <iker.gomez.vazquez@gmail.com> >> Subject: [Xansys] Re: APDL Command to Rename Directory >> >> Look at /syp command instead >> >> El mié, 17 de jul de 2024, 05:14, Matthew Ridzon, PE via Xansys < >> xansys-temp@list.xansys.org> escribió: >> >> > Folks, >> > >> > I'm writing an APDL script and would like to rename a file directory. >> > Is there a command for this? To my knowledge, /RENAME is for files >> > only, and not directories. >> > >> > I considered /SYS, but I cannot use APDL character substitution inside >> > of that command. >> > >> > Matt Ridzon, PE, MSME >> > Sr. Engineering Analyst >> > >> > Email matt@prime-engineer.com<mailto:matt@prime-engineer.com> >> > Mail 266 Main St, Burlington, VT 05401 >> > Web www.prime-engineer.com<http://www.prime-engineer.com/> >> > [A blue hexagon with white letters Description automatically >> > generated] PRIME ENGINEERING LLC >> > >> > >> > This message (including any attachments) may contain confidential, >> > proprietary, privileged and/or private information. The information is >> > intended to be for the use of the individual or entity designated >> > above. If you are not the intended recipient of this message, please >> > notify the sender immediately, and delete the message and any >> > attachments. Any disclosure, reproduction, distribution or other use >> > of this message or any attachments by an individual or entity other >> > than the intended recipient is prohibited. >> > >> > >> > _______________________________________________ >> > Xansys mailing list -- xansys-temp@list.xansys.org To unsubscribe send >> > an email to xansys-temp-leave@list.xansys.org If you are receiving too >> > many emails from XANSYS please consider changing account settings to >> > Digest mode which will send a single email per day. >> > >> > Please send administrative requests such as deletion from XANSYS to >> > xansys-mod@tynecomp.co.uk and not to the list >> _______________________________________________ >> Xansys mailing list -- xansys-temp@list.xansys.org To unsubscribe send >> an email to xansys-temp-leave@list.xansys.org If you are receiving too >> many emails from XANSYS please consider changing account settings to Digest >> mode which will send a single email per day. >> >> Please send administrative requests such as deletion from XANSYS to >> xansys-mod@tynecomp.co.uk and not to the list >> _______________________________________________ >> Xansys mailing list -- xansys-temp@list.xansys.org >> To unsubscribe send an email to xansys-temp-leave@list.xansys.org >> If you are receiving too many emails from XANSYS please consider changing >> account settings to Digest mode which will send a single email per day. >> >> Please send administrative requests such as deletion from XANSYS to >> xansys-mod@tynecomp.co.uk and not to the list > >
TR
Testi Riccardo
Thu, Jul 25, 2024 6:04 AM

Dear sirs,
would you mind letting me know whether the PRNSOL command outputs the requested quantities only at the nodes located on a body's surface? That's the behavior I observed with some tests.
Thank you very much

Best regards
Riccardo Testi

Development and Strategies
2 Wheeler Engines Technical Centre
Piaggio & C. S.p.A
Viale Rinaldo Piaggio, 25
56025 Pontedera (Pisa) - ITALY
Phone:  +39 0587 272850
Fax:        +39 0587 272010
Mobile: +39 339 7241918
E-mail:    riccardo.testi@piaggio.com

Dear sirs, would you mind letting me know whether the PRNSOL command outputs the requested quantities only at the nodes located on a body's surface? That's the behavior I observed with some tests. Thank you very much Best regards Riccardo Testi --- Development and Strategies 2 Wheeler Engines Technical Centre Piaggio & C. S.p.A Viale Rinaldo Piaggio, 25 56025 Pontedera (Pisa) - ITALY Phone: +39 0587 272850 Fax: +39 0587 272010 Mobile: +39 339 7241918 E-mail: riccardo.testi@piaggio.com
MG
Mohammad Gharaibeh
Thu, Jul 25, 2024 7:50 AM

Riccardo,

What are the PowerGraphics settings in your model?

Below is written in TFM:

PowerGraphics can affect your nodal solution listings. For PowerGraphics (
/GRAPHICS
https://www.mm.bme.hu/~gyebro/files/ans_help_v182/ans_cmd/Hlp_C_GRAPHICS.html,POWER),
results are listed for the model exterior surfaces only.

I hope this helps.

Best,
Mohammad

---====
Mohammad A Gharaibeh, Ph.D.
Associate Professor
Department of Mechanical Engineering
The Hashemite University
P.O. Box 330127
Zarqa, 13133, Jordan
Tel: +962 - 5 - 390 3333 Ext. 4771
Fax: +962 - 5 - 382 6348

---====

On Thu, 25 Jul 2024 at 9:06 AM Testi Riccardo via Xansys <
xansys-temp@list.xansys.org> wrote:

Dear sirs,
would you mind letting me know whether the PRNSOL command outputs the
requested quantities only at the nodes located on a body's surface? That's
the behavior I observed with some tests.
Thank you very much

Best regards
Riccardo Testi

Development and Strategies
2 Wheeler Engines Technical Centre
Piaggio & C. S.p.A
Viale Rinaldo Piaggio, 25
56025 Pontedera (Pisa) - ITALY
Phone:  +39 0587 272850
Fax:        +39 0587 272010
Mobile: +39 339 7241918
E-mail:    riccardo.testi@piaggio.com


Xansys mailing list -- xansys-temp@list.xansys.org
To unsubscribe send an email to xansys-temp-leave@list.xansys.org
If you are receiving too many emails from XANSYS please consider changing
account settings to Digest mode which will send a single email per day.

Please send administrative requests such as deletion from XANSYS to
xansys-mod@tynecomp.co.uk and not to the list

Riccardo, What are the PowerGraphics settings in your model? Below is written in TFM: PowerGraphics can affect your nodal solution listings. For PowerGraphics ( */GRAPHICS* <https://www.mm.bme.hu/~gyebro/files/ans_help_v182/ans_cmd/Hlp_C_GRAPHICS.html>,POWER), results are listed for the model exterior surfaces only. I hope this helps. Best, Mohammad ===================================== Mohammad A Gharaibeh, Ph.D. Associate Professor Department of Mechanical Engineering The Hashemite University P.O. Box 330127 Zarqa, 13133, Jordan Tel: +962 - 5 - 390 3333 Ext. 4771 Fax: +962 - 5 - 382 6348 ===================================== On Thu, 25 Jul 2024 at 9:06 AM Testi Riccardo via Xansys < xansys-temp@list.xansys.org> wrote: > Dear sirs, > would you mind letting me know whether the PRNSOL command outputs the > requested quantities only at the nodes located on a body's surface? That's > the behavior I observed with some tests. > Thank you very much > > Best regards > Riccardo Testi > --- > Development and Strategies > 2 Wheeler Engines Technical Centre > Piaggio & C. S.p.A > Viale Rinaldo Piaggio, 25 > 56025 Pontedera (Pisa) - ITALY > Phone: +39 0587 272850 > Fax: +39 0587 272010 > Mobile: +39 339 7241918 > E-mail: riccardo.testi@piaggio.com > > > _______________________________________________ > Xansys mailing list -- xansys-temp@list.xansys.org > To unsubscribe send an email to xansys-temp-leave@list.xansys.org > If you are receiving too many emails from XANSYS please consider changing > account settings to Digest mode which will send a single email per day. > > Please send administrative requests such as deletion from XANSYS to > xansys-mod@tynecomp.co.uk and not to the list >
